The Densen BEAT-200 is the result of over 3 years intensive research and development, providing the focal point for all future Densen products. As you would expect, it bears the Densen trademark of engaging musicality, but the BEAT-200 is also technically sophisticated and is fully engineered for the Gizmo system remote.  Soundwise the B-200 is – as with all other Densen products – designed with the absolute highest sound-quality as its goal. From the second the signal enters the B-200 there is no compromise. The input selection is done with a special version of CP Claire’s best relay. The CP Claire PRME 25005 is a mono relay, providing the B-200 with relays for both left and right signal - and a total of no less than 18 CP Claire relays, though the layout of the signal path means that the signal will travel through an absolute minimum of relays. From the input relays the signal is sent to the first stage of the preamp. Normally the signal would be sent directly to the potentiometer, but by starting with the first amplifier stage, the amplifier stage can be designed not only to take care of its normal function, but also to interact perfectly with the volume potentiometer that follows it. This ensures that signal sources with inferior output-stages will stil work perfectly with the B-200, because it is easier for them to work with the input stage rather then with a potentiometer that changes electrical ccharacteristics with the volume setting. From the volume potentiometer the signal is sent to the final stages of the B-200. The last stages are designed to be able to drive long cable runs, enabling it to work perfectly with several power amplifiers at once, even if they are placed alongway away from the B-200. This is done by making the output-stage a 6W Class-A power amplifier with no feedback… Naturally the amplifier stages are totally discrete designs, using ultrafast transistors and massive power supplies. The whole of the circuitry is designed with the best components, and as such all inputs are goldplated, all resistors are 1% laser-trimmed metalfilm or better, all capacitors are selected for their sonic quality, and a Alps RK27 motor-driven potentiometer is used in a 4 times version. The power supply is built with the same encapsulated transformers as in Densen's top of the line preamp, the DM-20. We use no less than 5 custom-made capacitors, with a total capacity of 50.000 uF. There are seperate transformers for audio and for the CPU/Link system. The design is optimised to perfection, with only a minimum of leaded components, the rest being high quality SMD components, mounted with a precision of 0.05 mm! There is used a special teflon double-sided PCB, which is highly unusual, but has dramatic effects on the signal quality. As always, the B-200 is prepared for bi-amping, but this time it is also prepared for quad-amping, allowing it to drive up to 4 stereo power amplifiers, or 8 monoblocks! If the connected power amplifier is Densen’s BEAT 300, it will be possible to make the system active by using electronic crossovers mounted internally in the BEAT B-300. This provides a clear upgrade path, from one B-200/B-300 to one B-200 and up to four B-300's using electronic crossovers, in an state-of-the-art active system. It is naturally possibile to mount a DP-01 phono-stage internally in the B-200. As allways with a Densen product, the circuit itself is built using no feedback, which results in an open, transparent and dynamic sound with the Densen trademark musical involvement in the foreground. The B-200 link system allows two-way communication in multiroom installations. It is made to be an intelligent system, where every product helps the others, so that IR signals recieved by the B-200 or another product are transferred to the product for which they are intented, securing a perfect reception of IR information. Each product will be avare of which other Densen products are in the system, allowing for problem free use of the remote etc. It will also be possible to take the remote to another room and control the link from there, or to use the remote in the main system like a normal remote. The whole link system interacts with a type D-Subconnector, and as such uses a computer standard, allowing for easy updating. The frontpanel functions are also improved, without sacrificing the Densen trademark of no-nonsense. One of the new features is stand-by, allowing not only the B-200 to be put in stand-by, but also all other connected Densen products. Another feature is the processor loop, allowing for the use of the forthcoming surround processor. To secure high quality sound in this multiroom system, the B-200 has also a seperate preamp stage for the link system, securing perfect quality, without interfering with the B-200’s main preamp. The link preamp is designed with a 833 IC which is run in balanced mode to secure no hum, even in link installations with long cableruns. Even though the 833 is of high quality, used in many of our competitors preamps, we feel it works best as a balanced amplifier in the link system, and that our discrete single-ended circuit is much better for real high-end use. All in all, this system is extremely versatile and will form the backbone of Densen products for many years to come. It is even prepared for extensions, meaning that the CPU, which is the heart of the system, can be updated. All these features are built into the BEAT-200 in a discrete way that never detracts from the true goal: musicality.
